Gruen 248 Movement Specifications, Beat Rate & Dimensions

Technical Caliber Datasheet

Manufacturer	Gruen
Caliber Reference	Gruen 248
Movement Type	Manual
Diameter (Lignes)	—
Diameter (mm)	13.05 mm
Height / Thickness	3.5 mm
Jewel Count	21 Jewels
Beat Rate / Frequency	18,000 BPH
Lift Angle	51°
Power Reserve	38 hours
Escapement	Swiss Lever
Production Period	1972

Historical Reference & Restoration Notes

The Gruen 248 is a celebrated example of vintage precision engineering. Featuring 21 jewels and operating at 18,000 BPH, surviving examples are prized by collectors and restorers.
